Bridge Tokscale is a small set of single-authority processes around one PostgreSQL database. Each process holds exactly one database role with a fenced SQL contract, so no component can reach a table it does not own. Three axes run through everything below, and keeping them apart is the central design choice: payment authorization, the usage receipt, and the epoch attestation are independent, so a failure on one axis never corrupts another.

​
The components

  • web console: the Next.js app, and the only local service published to the host. Sessions, project and key management, top-up flows, and console read models. It never joins the private chain network; its only chain reads go through a bounded method allowlist.
  • gateway: the Rust service, default bind 127.0.0.1:8788. Authenticates tok_ keys, enforces per-project policy, admits credit or x402 payment, dispatches to the model provider, settles, and serves issued receipts. See The Gateway and Its Workers.
  • x402 adapter: an isolated process on port 8090, and the only component that talks to the facilitator, the chain RPC, and the append-only settlement journal. A framework version mismatch forces the boundary, and the seam is a bearer-authenticated local JSON interface. See x402 Payments on GIWA.
  • facilitator: a digest-pinned x402-rs image that verifies and broadcasts x402 settlements for eip155:91342. Self-hosted because Coinbase’s hosted facilitator does not support GIWA.
  • postgres: the system of record. Migrations are checksum-pinned, the database is bound once and immutably to a deployment identity, and the request ledger is append-only: a BEFORE UPDATE OR DELETE trigger raises giwa request ledger is append-only on any mutation. Ten least-privilege roles replace any shared superuser at runtime.
  • redis: session and console cache. No financial state.
  • workers: the receipt issuer, the top-up reconciler, the attestation publisher, and the terminal-retention poller. Each is a bounded one-shot process, polled rather than long-running. See The Gateway and Its Workers.
  • the chain: locally a disposable Anvil chain that borrows chain ID 91342 with a fixed genesis timestamp; in the production-shaped topology, real GIWA Sepolia. Chain ID is not a network identity here. See Network Separation.

​
How one paid request moves through it

Five durable stages, each of which either completes or leaves a recoverable record.
1

Authenticate and admit

The client calls a native route with an Authorization: Bearer tok_… key:
The gateway resolves the key to a project, pins the active policy decision (model allowlist, lifetime spend cap), and checks payment. A prepaid-credit request takes a conservative maximum admission under a per-project PostgreSQL session lease. An x402 request without a signature gets a 402 with a body-aware maximum quote, then retries with a signed PAYMENT-SIGNATURE header; the adapter verifies it against the facilitator before any intent exists.
2

Dispatch to the provider

A durable request intent and outbox row are written in one transaction. Provider dispatch is idempotent on the payment identifier, so a retry cannot cause a second provider call.
3

Settle actual usage

When the terminal artifact is in hand, usage is priced against the same pricing snapshot bound at admission. Credits settle exact-decimal, never above the admission. x402 upto settles the actual amount, never above the signed maximum, through the adapter, the facilitator, and the canonical Upto Permit2 proxy on-chain. A client disconnect does not strand settlement: a background commit task finishes it out of band.
4

Write the ledger row and issue the receipt

The outcome lands as one immutable row in the request ledger. The receipt issuer, a separate least-privilege worker, signs an EIP-712 UsageReceiptV1. The client retrieves it:
For detailed instructions, see UsageReceiptV1.
5

Anchor the epoch attestation

The attestation publisher collects sealed receipts for an epoch, builds the epoch Merkle tree under the V1 merkle domain separators, and publishes exactly one EAS transaction carrying the epoch summary commitment. Cost per epoch is constant in request count. For detailed instructions, see Receipt Attestation.

​
Which stages are proven where

Stages 1 through 4 run end to end on the local localnet today. Stage 1’s Stage A exact settlement is additionally proven once on public GIWA Sepolia (tx 0xad1a2f7b…fcb9f8, 1.0 tUSD, replay-rejected on retry). Stage 5 is proven against the local EAS fixture only; anchoring the first public Usage Root on Sepolia is still ahead of us. Live Evidence is the authoritative split. The local evidence is local on purpose. The topology borrows the GIWA Sepolia chain ID so the V1 wire format stays byte-identical to the public chain, which means chain ID cannot be the safety boundary: identity comes from GIWA_NETWORK plus an immutable database binding, and a local artifact never earns a Sepolia explorer link. See Network Separation.

​
What the end-to-end harness adds

The harness results below are maintainer-run. The gateway stack and its harness are not publicly available, so they are attributed evidence rather than reader instructions. The shipped client surface is the open-source CLI (see Quickstart: Track Your Usage).
One full pass wraps the five stages above in the things a real session needs and a real auditor would ask for:
  • Wallet sign-in. A deterministic Anvil account completes Sign-In with Ethereum against the console. See Dual Identity.
  • A credit top-up before any request. The account receives a durable 402 quote, mints test-only tUSD, and signs a real EIP-3009 authorization. The facilitator settles it, and the reconciler independently observes the calldata and events before recording exactly one credit. See x402 Stage A.
  • Credential-free browser verification. A Playwright container with no session, API key, wallet key, database URL, or server secret receives only a holder-disclosable handoff. It verifies the receipt, loads the Passport proof, and writes sealed artifacts, which the outer harness then re-verifies read-only.
Two markers report the outcome:
GIWA_LOCAL_E2E_OK is the authoritative local proof marker. It is emitted only after the integration journey, the browser artifact verification, the chain-restart check, and the tamper-negative checks all pass, so a pass that skips or fails any of those does not print it. GIWA_BROWSER_ARTIFACTS names which sealed artifacts were re-verified.

​
Topologies

The default stack is sealed: only the console port reaches the host, and every key inside it is a publicly known Anvil development key valid nowhere else.
  • Sealed localnet, the default: the full hermetic proof, with least-privilege database roles, checksum-pinned migrations, the deployment-identity binding, Anvil at chain ID 91342 with persisted state, the facilitator, the adapter, the gateway, the workers, and the console. The gateway stays on the internal network.
  • Production-shaped: the console and gateway against real GIWA Sepolia, with the test provider disabled, every secret a required variable, and no Anvil or facilitator inside. This is a topology definition; no public deployment is running.
  • Fault injection: two overlays that inject real failures. One slows the reconciler so it can be killed after a real EIP-3009 settlement but before observation, proving exactly-one crediting after restart. The other puts the adapter behind a one-shot response-loss proxy, proving single-settlement recovery.

​
Evidence

The whole lifecycle, including the browser checks, runs under one harness target, pinned to a fixed buildx builder so image builds resolve identically on every pass:
A second target kills the reconciler after a real settlement and proves it credits exactly once on restart:
A third drops the adapter’s settle response after a real on-chain settlement and proves read-only recovery:

​
